Amazon RDS: How to perform RMAN operations?

Hi all,

Need to performa any RMAN Operation from Amazon RDS? Maybe something like validating backups?

Well, we have some options under by using RDSADMIN_RMAN_UTIL package. See below an example for validate backup:

BEGIN
 rdsadmin.rdsadmin_rman_util.validate_database(
 p_validation_type => 'PHYSICAL+LOGICAL',
 p_parallel => 4,
 p_section_size_mb => 10,
 p_rman_to_dbms_output => FALSE);
END;
/

More info about it: https://docs.aws.amazon.com/AmazonRDS/latest/UserGuide/Appendix.Oracle.CommonDBATasks.RMAN.html

Hope it helps, cheers!

AWS RDS: Read Oracle Traces from SQL*Plus

Hi all,

One more for AWS services. Let’s say you need to read tracefiles from RDS, hot to do it?

Here is an example on how to list and read those files:

SQL> select * from dba_directories;

OWNER DIRECTORY_NAME DIRECTORY_PATH ORIGIN_CON_ID
---------- ------------------------- ------------------------------------------------------------ -------------
SYS BDUMP /rdsdbdata/log/trace 0
SYS ADUMP /rdsdbdata/log/audit 0
SYS OPATCH_LOG_DIR /rdsdbbin/oracle/QOpatch 0
SYS OPATCH_SCRIPT_DIR /rdsdbbin/oracle/QOpatch 0
SYS DATA_PUMP_DIR /rdsdbdata/datapump 0
SYS OPATCH_INST_DIR /rdsdbbin/oracle/OPatch 0
SYS TMP /rdsdbdata/userdirs/01 0

7 rows selected.


SQL> select * from table (rdsadmin.rds_file_util.read_text_file( p_directory => 'BDUMP', p_filename => 'trace/CPROD1_s003_81573.trc'));


From the trace file:
=========================
..................................................................................
index undo for leaf key operations
KTB Redo
op: 0x02 ver: 0x01
compat bit: 4 (post-11) padding: 1
op: C uba: 0x000e289e.51da.47
Dump kdilk : itl=98, kdxlkflg=0x1 sdc=0 indexid=0x1c53db block=0x0019bdc0
(kdxlpu): purge leaf row
key :(24):
07 78 76 0c 17 17 09 32 08 c7 07 1a 02 28 15 01 18 06 00 1a 3c 99 00 1e

File 3 is not mirrored.

End dump previous blocks for kdsgrp
* kdsgrp1-2: ***********************************************
kdsDumpState: RID context dump

45511581 rows selected.

SQL> select * from table (rdsadmin.rds_file_util.listdir( p_directory => 'BDUMP')) order by mtime;

FILENAME TYPE FILESIZE MTIME
---------------------------------------- ---------- ---------- ---------
CPROD1_ora_48800.trm file 73 24-DEC-18
CPROD1_ora_48800.trc file 998 24-DEC-18
CPROD1_ora_86597.trc file 998 24-DEC-18
CPROD1_ora_86597.trm file 73 24-DEC-18
CPROD1_ora_7999.trc file 881 24-DEC-18
CPROD1_ora_7999.trm file 71 24-DEC-18
CPROD1_ora_7997.trm file 71 24-DEC-18
CPROD1_ora_7997.trc file 881 24-DEC-18
CPROD1_ora_8240.trm file 71 24-DEC-18
CPROD1_ora_8240.trc file 881 24-DEC-18
CPROD1_ora_8381.trm file 72 24-DEC-18
CPROD1_ora_8381.trc file 995 24-DEC-18
CPROD1_ora_8540.trc file 881 24-DEC-18
CPROD1_ora_8540.trm file 71 24-DEC-18
CPROD1_ora_9876.trc file 881 24-DEC-18
CPROD1_ora_9876.trm file 71 24-DEC-18
CPROD1_ora_11142.trm file 72 24-DEC-18
CPROD1_ora_11142.trc file 883 24-DEC-18
CPROD1_ora_11182.trc file 883 24-DEC-18
CPROD1_ora_11182.trm file 72 24-DEC-18
CPROD1_ora_55077.trm file 73 24-DEC-18
CPROD1_ora_55077.trc file 997 24-DEC-18
CPROD1_ora_92260.trm file 73 24-DEC-18
CPROD1_ora_92260.trc file 997 24-DEC-18
CPROD1_ora_123869.trc file 1000 24-DEC-18
CPROD1_ora_123869.trm file 74 24-DEC-18
CPROD1_ora_41305.trc file 998 24-DEC-18
CPROD1_ora_41305.trm file 73 24-DEC-18
CPROD1_j002_3293.trc file 114049 24-DEC-18
CPROD1_j002_3293.trm file 370 24-DEC-18
CPROD1_mmon_71739.trc file 7511332 24-DEC-18
CPROD1_mmon_71739.trm file 738330 24-DEC-18
CPROD1_ora_92888.trc file 997 24-DEC-18
CPROD1_ora_92888.trm file 73 24-DEC-18
trace/ directory 323584 24-DEC-18
alert_CPROD1.log file 204808 24-DEC-18
CPROD1_ora_70145.trc file 1470 24-DEC-18
CPROD1_ora_70145.trm file 109 24-DEC-18

3845 rows selected.

SQL> select * from table (rdsadmin.rds_file_util.listdir( p_directory => 'BDUMP')) where filename like '%CPROD1_s003_81573.trc%';

FILENAME TYPE FILESIZE MTIME
---------------------------------------- ---------- ---------- ---------
CPROD1_s003_81573.trc file 1948134047 23-DEC-18



AWS: ALTER SYSTEM and Managing SYS Objects in RDS

I’m very often managing services over EC2 and there are a few actions clients are often getting some issues to perform in RDS. So I decided to list here 5 of them:

Kill sessions:

begin
rdsadmin.rdsadmin_util.kill(
sid => &sid,
serial => &serial,
method => 'IMMEDIATE');
end;
/

Flush shared_pool or buffer_cache:

exec rdsadmin.rdsadmin_util.flush_shared_pool;
exec rdsadmin.rdsadmin_util.flush_buffer_cache;

Grant Privileges to SYS Objects

# Grant

begin
    rdsadmin.rdsadmin_util.grant_sys_object(
        p_obj_name  => 'V_$SESSION',
        p_grantee   => 'GREPORA',
        p_privilege => 'SELECT');
end;
/

# Grant with Grant Option

begin
    rdsadmin.rdsadmin_util.grant_sys_object(
        p_obj_name     => 'V_$SESSION',
        p_grantee      => 'GREPORA',
        p_privilege    => 'SELECT',
        p_grant_option => true);
end;
/

# Revoke

begin
    rdsadmin.rdsadmin_util.revoke_sys_object(
        p_obj_name  => 'V_$SESSION',
        p_revokee   => 'GREPORA',
        p_privilege => 'SELECT');
end;
/



Hope it Helps!

AWS EC2: Custom Functions to Verify Passwords

Hello all!
Looking forward to create password functions on EC2? Easy, we just need to use AWS internal functions for it. Check below an example:

# To create it:

begin
    rdsadmin.rdsadmin_password_verify.create_verify_function(
        p_verify_function_name => 'CUSTOM_PASSWORD_FUNCTION',
        p_min_length           => 12,
        p_min_uppercase        => 2,
        p_min_digits           => 1,
        p_min_special          => 1,
        p_disallow_at_sign     => true);
end;
/

In case you want to double check the code created, here goes a quick trick: Check on DBA_SOURCE:

col text format a150
  select TEXT  from DBA_SOURCE
   where OWNER = 'SYS' and NAME = 'CUSTOM_PASSWORD_FUNCTION' order by LINE;

Hope it helps. Cheers!

AWS EC2: Grant Privileges to SYS Objects

Hello all!
So quick one today: How to grant and revoke privileges from/to SYS objects on EC2 instances? Do we have the ‘grant option’ for those grants?

Easy, have a look:

# Grant

begin
    rdsadmin.rdsadmin_util.grant_sys_object(
        p_obj_name  => 'V_$SESSION',
        p_grantee   => 'GREPORA',
        p_privilege => 'SELECT');
end;
/

# Grant with Grant Option

begin
    rdsadmin.rdsadmin_util.grant_sys_object(
        p_obj_name     => 'V_$SESSION',
        p_grantee      => 'GREPORA',
        p_privilege    => 'SELECT',
        p_grant_option => true);
end;
/

# Revoke

begin
    rdsadmin.rdsadmin_util.revoke_sys_object(
        p_obj_name  => 'V_$SESSION',
        p_revokee   => 'GREPORA',
        p_privilege => 'SELECT');
end;
/

Amazon EC2: X11 Forwarding After Sudo SSH Session

Hello all!

So, now with more use of resources like Cloud servers, more and more silent instalations are being done, right? Myself, I do it in silent always I can.

What if I need to export X. Plus, if I need to export it from user oracle, but I can only login with ec2-user, as usual?

Here is the process for that:

1) Connect to AWS EC2 instance

[user@securehost ~]$ ssh -X ec2-user@ipaddress
Last login: Fri Dec 7 14:41:41 2018 from grepora.srv.com
__| __|_ )
 _| ( / Amazon Linux AMI
 ___|\___|___|
https://aws.amazon.com/amazon-linux-ami/2018.03-release-notes/
13 package(s) needed for security, out of 16 available
Run "sudo yum update" to apply all updates.

2) Test xclock works from ec2-user

[ec2-user@ipaddress ~]$ xclock
Warning: Missing charsets in String to FontSet conversion
^C

3) Show all magic cookie

[ec2-user@ipaddress ~]$ xauth list
ipaddress/unix:12 MIT-MAGIC-COOKIE-1 7e53e7600ff4177d7bbc66bde0a1b1ca
ipaddress/unix:11 MIT-MAGIC-COOKIE-1 e3d1a8915484c929ef3e809b047e6352
ipaddress/unix:10 MIT-MAGIC-COOKIE-1 07b3de3093cef835c19239ea952231b7

4) Show DISPLAY variable

[ec2-user@ipaddress ~]$ env|grep DISPLAY
DISPLAY=localhost:10.0

5) Create /tmp/xauth based on current DISPLAY variable

[ec2-user@ipaddress ~]$ xauth list | grep unix`echo $DISPLAY | cut -c10-12` > /tmp/xauth
[ec2-user@ipaddress ~]$ ll /tmp/xauth ; cat /tmp/xauth
-rw-rw-r-- 1 ec2-user ec2-user 78 Dec 7 14:47 /tmp/xauth
ipaddress/unix:10 MIT-MAGIC-COOKIE-1 07b3de3093cef835c19239ea952231b7

6) Sudo to oracle

[ec2-user@ipaddress ~]$ sudo su - oracle
Last login: Fri Dec 7 14:43:12 UTC 2018 on pts/0

7) Add and Verify xauth

[oracle@ipaddress ~]$ xauth add `cat /tmp/xauth`
[oracle@ipaddress ~]$ xauth list
ipaddress/unix:10 MIT-MAGIC-COOKIE-1 07b3de3093cef835c19239ea952231b7

8) Verify and Add DISPLAY variable

[oracle@ipaddress ~]$ env|grep DISPLAY
[oracle@ipaddress ~]$ export DISPLAY=localhost:10.0

9) Test xclock works from oracle

[oracle@ipaddress ~]$ xclock
Warning: Missing charsets in String to FontSet conversion
^C
[oracle@ipaddress ~]$

Now you should be able to see the clock and so other graphical resources, like DBCA and so on.

Hope it helps!
